Tumbler Dryer 100kg--All Stainless Steel

Brief of Tumbler dryer

1 .INNER CYLINDER OF POLISHED STAINLESS STEEL QUALITY AISI 304. - INNER CYLINDER OF POLISHED STAINLESS STEEL QUALITY AISI 304

2. WITH SCHNERDER’S AC ELECTRONIC PARTS

3.MICROPROCESSOR THAT REGULATES CYCLES AND THERMAL ACTION DURING THE DRYING CYCLE.

4. PROGRESSIVE COOLING SYSTEM AT THE END OF THE CYCLE TO AVOID WRINKLES IN GARMENTS WITH MODIFIABLE TIMES. SISTEMA DE ENFRIAMIENTO PROGRESIVO AL FINAL DEL CICLO PARA EVITAR ARRUGAS EN LAS PRENDAS CON TIEMPOS MODIFICABLES.

5. DRYER INDICATOR LAMPS RUNNING, HEATING IN PROGRESS AND CLEAN THE FILTER

VISUAL AND AUDITORY ALARM INDICATING THE COMPLETION OF THE PROCES

6. FRONT AND SIDE PANELS MADE OF STAINLESS STEEL PLATE QUALITY AISI 304.

STAINLESS STEEL DOOR WITH THERMAL VISOR GLASS, WITH SECURITY LOCKING

Character of this tumbler dryer

The drum is made from high-quality stainless steel to prolong working life
Big-size door is adopted for convenient fabric feeding and taking as well as transparent toughened glass is equipped for convenient view of fabric drying condition.
High-power heater is adopted to guarantee safe and effective drying effect.
Self-cleaning lint filter is equipped to avoid lint jam.

MACHINE'S MAIN PARTS:

Stainless steel rotating drum
Copper heat radiator
Two or three motors
Exhust fine
Operating system
Steel body

Model HGQ100
Capacity 100kg
Drum dimension 1480mm*950mm
Drum Speed 30rpm
Motor power 2.2kw
Fan power 1.1kw*2
Overall dimension 1440mm*1840mm*2400mm
Weight 980kg
