Character of 100kgs Automatic Washer Extractor
1. This washer extractor has function of washing and extracting
2. The shell and drums are all made of all stainless steel
3 With Stainles steel durable bearing and locking system ,during running the high speed extracting ,the bearing system will get more and more fasten
4 With Effecient shock absorber and Springs make high speed extracting stable and smooth
5 This heavu duty washer extractor has friendly programmable operating panel and working plateform , which contains more than 30 programs, and each program is able to have more than 30 working steps .Operator is able to modify the washing programs by their request
g . Branded requency controller(Invert ) is equipped with this laundry washer extractor . Besides, when the machine is braked. The invert will stop the machine together with the damper, will make it more efficient and make the machine last long time.
6. The whole system is made of Micro computer and air operated valve system, which will enlong the life of the whole machine, and the door lock system will ensure the safety of the operator
The new XGQ-F series washer-extractors are available in15kgs,20kgs, 25kgs, 50kgs,70kgs and 100 KGS capacities.
Model XGQ-100F
Rated capacity(kg): 100kg
Drum capacity(L): 1000L
Motor power(kw): 7.5KW
Washing rotate(rpm): 30
Dewatering rotate(rpm): 650
Steam pressure (Mpa): 0.4-0.5
Overall dimensions(mm): 1600*10*2000
Weight(kg): 3200
Our products are ISO9001 & CE certified.
Terms of payment: T/T
Model | XGQ-50F | XGQ-70F | XGQ-100F |
Rated capacity | 50kg | 70kg | 100kg |
Drum dimension | 1080×600 | 1080*720mm | 1200×840 |
Motor power | 4kw | 5.5kw | 7.5kw |
Rotation | 38rpm-720rpm | 84rpm-650rpm | 33rpm-650rpm |
Inventor power | 4kw | 5.5 | 11 kw |
Electricity heating power | 24kw | 24kw | 48kw |
Water inlet | 3/2’ | 3/2’’ | 11/2” |
Steam inlet | 1” | 1’ | 1” |
Chemicals inlet | 1/2” |
| 1/2” |
Overall dimension | 1620*1600*1600 | 1850*1600*1720 | 1600*1870*2000 |
Weight | 2000kg | 2500kg | 3200kg |
