Working Theory of Medical Sanitary Washing Machine :
A gem-free , dust-free ,anti-static washing .
B With help of our barrier washer extractor ,you are able to divide the laundry room into two separate independent operating areas ,Viz :" Clean and Non Clean " area .
C Launderettes will be loaded into the wasing machine through the door from the "Non-clean " area . After washing ,unloading will be from the "clean " area ,with clean air control system ,it ill effectively revent gems and dust from "Non-clean " room
D Thus it prevents the clean launderrete from being contaminated again and get infecte
The specification of 50kg washer extractor is as follows
Model BW-50F
Rated capacity(kg): 50kg
Drum capacity(L): 500L
Motor power(kw): 5.5KW
Inventor power: 7.5 kw
Washing rotation (rpm): 30rpm-35rpm
Dewatering rotation (rpm): 650rpm to 750rpm
Steam pressure (Mpa): 0.4-0.5
Overall dimensions(mm): 1580*2120*2800
Weight(kg): 2000
Our products are ISO9001 & CE certified.
Terms of payment: T/T/LC
Character of this Medical Barrier Washing machine Mahcinne is as follows
A Barrier wall two doors design seperate soiled and clean side for anti-contamintion Enviroment (Perfect for cleanroom and healthcare laundry
B Parts in contact with water made of ss304 stainless steel
C Automatic inner Drum Positioning stops the drum at ergonomic loading and unloading position
D Electro-polished drum gives maximum protection to wash items
E Frequency inverter drive allows variable speed setting
F Spring and Shock absorber suspension system ensure quiet and smooth extraction
G User freindly touch screen computer in English
H Patented security key design insure inner door of drum is always locked before machine operation
I Standard cold and hot water inlet valves and on drain valve
J Direct steam injection heating system and electricity heated system is avirable
K Automatic soapbox Compartments is able to be connected to liquid chemical pump system
L Sight glass to vier the inner drum
M Saftey door interlock system
N Out of balance switch form machine protection
model | BW30 | BW50 |
rated capcity （kg） | 30 | 50 |
drum | diameter（mm） | Φ800 | Φ900 |
| depth （mm） | 600 | 800 |
| volume （L） | 301 | 508 |
heated by | Electric/Steam | Electric/STEAM |
G-FORCE | 320 | 320 |
power （V/Hz） | 380 |
|
motor （kw） | 4 | 5.5 |
inventor power （kw） | 5.5 | 7.5 |
pipe port | water | 25 | 25 |
| steam | 25 | 25 |
| water exhaust | 980 | 980 |
air compress （MPa） |
|
|
water consumption （kg） | 1000 | 1200 |
electricity consumption （kwh） | 1.5 | 2.1 |
over all dimension (l*w*h) （mm） | 1540*1480*1650 | 1710*1590*1715 |
weight （kg） | 1500 | 1900 |
