The drying machine's drum and outter panel are made of stainless steel, outter painting is heated by electricity with digital operating panel
The machine has the facility of cooling that would be very safe for the opeartor.
The drying machine 's capacity is avialible in 15kgs, 30 kgs, 50kgs 100kgs 120kgs, 150kgs are mainly for hotels, laundries and hospitals textile factory,
Specification
Model HGQ120
Capacity 120kg
Drum dimension:; 1480mm*1110mm
Rotation spped 33rpm
Steam pressure 0.4Mpa to 0.5Mpa
Motor power 2.2kw
Fan power 1.5kw
Overall dimension 1580mm*1840mm*2400mm
The drying machine's drum and outter panel are made of stainless steel, outter painting is heated by electricity with digital operating panel
The machine has the facility of cooling that would be very safe for the opeartor.
The drying machine 's capacity is avialible in 15kgs, 30 kgs, 50kgs 100kgs 120kgs, 150kgs are mainly for hotels, laundries and hospitals textile factory,
Specification
Model HGQ120
Capacity 120kg
Drum dimension:; 1480mm*1110mm
Rotation spped 33rpm
Steam pressure 0.4Mpa to 0.5Mpa
Motor power 2.2kw
Fan power 1.5kw
Overall dimension 1580mm*1840mm*2400mm
model | HGQ15 | HGQ30 | HGQ50 | HGQ100 | HGQ120 | HGQ150 |
capacity | 15KG | 30Kg | 50Kg | 100Kg | 120kg | 150kG |
drum | Φ 760mm*560mm | Φ 900mm*750mm | Φ 1050*930 | Φ 1320*1055 | Φ 1470*1055 | Φ 1660*1150 |
drum speed | 33rpm | 33rpm | 33rpm | 33rpm | 33rpm | 28rpm |
electronic heating | 12kw | 16.2kw | 27 | ----- | --- | --- |
steam heating | 0.4Mpa to 0.5Mpa | 0.4Mpa to 0.5Mpa | 0.4 t0 0.5 Mpa | 0.4 to 0.5 Mpa | 0.4to 0.5Mpa | 0.4to 0.5MPa |
motor power | 0.75kw | 1.1kw | 1.5kw | 2.2kw | 3kw | 4kw |
fan power | 0.55kw | 1.1kw | 1.1kw | 1.5kw | 1.5kw*2 | 1.5kw*2 |
overall dimension | 860mm*760mm*1720mm | 1000*140*1800 | 1190*1670*2100 | 1480*1840*2380 | 1660*1840*2470 | 1760*2000*2730 |
model | HGQ15 | HGQ30 | HGQ50 | HGQ100 | HGQ120 | HGQ150 |
capacity | 15KG | 30Kg | 50Kg | 100Kg | 120kg | 150kG |
drum | Φ 760mm*560mm | Φ 900mm*750mm | Φ 1050*930 | Φ 1320*1055 | Φ 1470*1055 | Φ 1660*1150 |
drum speed | 33rpm | 33rpm | 33rpm | 33rpm | 33rpm | 28rpm |
electronic heating | 12kw | 16.2kw | 27 | ----- | --- | --- |
steam heating | 0.4Mpa to 0.5Mpa | 0.4Mpa to 0.5Mpa | 0.4 t0 0.5 Mpa | 0.4 to 0.5 Mpa | 0.4to 0.5Mpa | 0.4to 0.5MPa |
motor power | 0.75kw | 1.1kw | 1.5kw | 2.2kw | 3kw | 4kw |
fan power | 0.55kw | 1.1kw | 1.1kw | 1.5kw | 1.5kw*2 | 1.5kw*2 |
overall dimension | 860mm*760mm*1720mm | 1000*140*1800 | 1190*1670*2100 | 1480*1840*2380 | 1660*1840*2470 | 1760*2000*2730 |
Industrial drying machine is a kind of equipment that is dried by hot air, which can dry wool, cotton clothes, bed sheets and quilt covers
1. It adopts computer automatic control, and can configure different drying temperature and drying time according to drying requirements to realize automatic drying.
2 The inner drum is made of bright stainless steel with excellent heat resistance, the inner wall is smooth, and the wear of clothes is reduced
3 Equipped with a high-efficiency radiator and a reasonable air duct, so that the hot air directly contacts the clothes, which greatly improves the drying efficiency and saves energy.
4 There are various models such as external steam radiator or electric heating radiator, or natural gas radiator to choose from
