Jiangsu Sunflower Machinery Co,.ltd
| Availability: | |
|---|---|
| Quantity: | |
And this paddle dyeing machine can also be applied as industrial washing machine or washer in hotels or hospitals
Character
It has English operating panel
This paddle deying machine is made of all stainless 304
It has steam inlet port and get temperature tube at the bottom of the machine. This machine can be heated directly or indirectly
Besides you can also keep the temperature inside the drum, by the advatage of the temperature tube
The capacity of this machine is from 30kg 50kg 100kg 150kg, 200kg, 250kg, 300kg, 400kg
Specification
Model ssx300
Capacity 300kg
Motor power 7.5kw
Drum dimension Φ 1280*2235
Overall dimension 3240mm*2400mm*2150mm
Weight 1850kg
And this paddle dyeing machine can also be applied as industrial washing machine or washer in hotels or hospitals
Character
It has English operating panel
This paddle deying machine is made of all stainless 304
It has steam inlet port and get temperature tube at the bottom of the machine. This machine can be heated directly or indirectly
Besides you can also keep the temperature inside the drum, by the advatage of the temperature tube
The capacity of this machine is from 30kg 50kg 100kg 150kg, 200kg, 250kg, 300kg, 400kg
Specification
Model ssx300
Capacity 300kg
Motor power 7.5kw
Drum dimension Φ 1280*2235
Overall dimension 3240mm*2400mm*2150mm
Weight 1850kg
| model | capacity(kg) | motor power(kw) | drum(mm) | over all dimension (mm) | weight kg |
| Ssx30 | 30 | 1.1kw | Φ 700*860 | 1600*880*1400 | 650 |
| Ssx50 | 50 | 1.5 | Φ 700*1000 | 1810*910*1400 | 680 |
| Ssx70 | 70 | 2.2 | Φ 850*1400 | 1870*1100*1650 | 750 |
| Ssx100 | 100 | 3 | Φ 980*1400 | 2560*1570*2140 | 800 |
| Ssx150 | 150 | 4 | Φ 1080*1660 | 2560*1570*2140 | 1050 |
| sSx200 | 200 | 5.5 | Φ 1080*2000 | 2900*1600*1760 | 1200 |
| Ssx250 | 250 | 7.5 | Φ 1200*2200 | 3100*1858*1900 | 1500 |
| Ssx270(air operated ) | 270 | 15 | Φ 1800*1500 | 2840*2200*2500 | 3900 |
| sSx300 | 300 | 7.5 | Φ 1280*2235 | 3240*2400*2150 | 1850 |
| Ssx400 | 400 | 11 | Φ 1500*2400 | 3400*2500*2200 | 3000 |
| this machine can be heated by steam directly or indirectly and this machine are made of all stainless steel | |||||
| model | capacity(kg) | motor power(kw) | drum(mm) | over all dimension (mm) | weight kg |
| Ssx30 | 30 | 1.1kw | Φ 700*860 | 1600*880*1400 | 650 |
| Ssx50 | 50 | 1.5 | Φ 700*1000 | 1810*910*1400 | 680 |
| Ssx70 | 70 | 2.2 | Φ 850*1400 | 1870*1100*1650 | 750 |
| Ssx100 | 100 | 3 | Φ 980*1400 | 2560*1570*2140 | 800 |
| Ssx150 | 150 | 4 | Φ 1080*1660 | 2560*1570*2140 | 1050 |
| sSx200 | 200 | 5.5 | Φ 1080*2000 | 2900*1600*1760 | 1200 |
| Ssx250 | 250 | 7.5 | Φ 1200*2200 | 3100*1858*1900 | 1500 |
| Ssx270(air operated ) | 270 | 15 | Φ 1800*1500 | 2840*2200*2500 | 3900 |
| sSx300 | 300 | 7.5 | Φ 1280*2235 | 3240*2400*2150 | 1850 |
| Ssx400 | 400 | 11 | Φ 1500*2400 | 3400*2500*2200 | 3000 |
| this machine can be heated by steam directly or indirectly and this machine are made of all stainless steel | |||||
Industrial drying machine is a kind of equipment that is dried by hot air, which can dry wool, cotton clothes, bed sheets and quilt covers
1. It adopts computer automatic control, and can configure different drying temperature and drying time according to drying requirements to realize automatic drying.
2 The inner drum is made of bright stainless steel with excellent heat resistance, the inner wall is smooth, and the wear of clothes is reduced
3 Equipped with a high-efficiency radiator and a reasonable air duct, so that the hot air directly contacts the clothes, which greatly improves the drying efficiency and saves energy.
4 There are various models such as external steam radiator or electric heating radiator, or natural gas radiator to choose from
