Jiangsu Sunflower Machinery Co,.ltd
Tumble dryer, tumbler dryer, industrial drying machine, laundry machine, laundry dryer, laundry equipment, textile dryer, jeans dryer, uniform dryer.
The machine's drum is made of stainless steel, and it is totally automatic
And also the machine has the facility of cooling that would be very safe for the opeartor.
The machine which capacity is range from 30 kgs to 100kgs are mainly for hotels, laundries and hospitals anf the machine which capacity is range from 100kgs to 150kgs is mainly for textile factory, leather factory if you are interested in our machine, please not hesitate to leave us a message and we will response to it in time.
Availability: | |
---|---|
Quantity: | |
| |
HGQ-30
SUNFLOWER
84512900
30kg Best Price Fabric, Linen, Garment, Cloth Commercial Clothes Tumble Dryers
Tumbler dryer is perfect machine to do drying job of the towels, bed covers and so on for laundry shops, hospitals and hotels.
This machine will work together with washer extractor or industrial washing machine to make the fabric 100% dried by hot air.
The drum is made from high-quality stainless steel, we can also make the machines covered by all stainless steel.
Tumble dryer's outter cover painting is polished and heated, that makes the machine looks much perfect
Can be heated by electricity or steam that 15kg 30kg 50kg dryer can heated by either steam or electricity, but the dryer 100kg can only be heated by steam
Big-size door is adopted for convenient fabric feeding and taking as well as transparent toughened glass is equipped for convenient view of fabric drying condition.
Model | HGQ15 | HGQ30 | HGQ50 | HGQ100 | HGQ150 | HGQ200 | ||
Rated capacity | 15 | 30 | 50 | 100 | 150 | 200 | ||
Drum capacity | 760*560 | 900×750 | 1050×930 | 1320×1055 | 1600×1150 | 1300×2150 | ||
Drun speed | 33 | 33 | 33 | 33 | 28 | 33 | ||
Heated term | 12.6kw | Steam pressure:0.294-0.588MPa Voltage:380V Three phase four wire | ||||||
Motor power | 0.75 | 1.1 | 1.5 | 2.2 | 4 | 3 | ||
Breeze motor power | 0.75 | 1.1 | 1.1 | 1.5 | 1.5×2 | 2.2 | ||
Overall dimensions | 800*1020*1530 | 1000×1400×1800 | 1190×1670×2100 | 1480×1840×2380 | 1760×200×2730 | 2650×1630×2720 | ||
Overall weight | 250 | 600 | 800 | 980 | 1300 | 1500 |
30kg Best Price Fabric, Linen, Garment, Cloth Commercial Clothes Tumble Dryers
Tumbler dryer is perfect machine to do drying job of the towels, bed covers and so on for laundry shops, hospitals and hotels.
This machine will work together with washer extractor or industrial washing machine to make the fabric 100% dried by hot air.
The drum is made from high-quality stainless steel, we can also make the machines covered by all stainless steel.
Tumble dryer's outter cover painting is polished and heated, that makes the machine looks much perfect
Can be heated by electricity or steam that 15kg 30kg 50kg dryer can heated by either steam or electricity, but the dryer 100kg can only be heated by steam
Big-size door is adopted for convenient fabric feeding and taking as well as transparent toughened glass is equipped for convenient view of fabric drying condition.
Model | HGQ15 | HGQ30 | HGQ50 | HGQ100 | HGQ150 | HGQ200 | ||
Rated capacity | 15 | 30 | 50 | 100 | 150 | 200 | ||
Drum capacity | 760*560 | 900×750 | 1050×930 | 1320×1055 | 1600×1150 | 1300×2150 | ||
Drun speed | 33 | 33 | 33 | 33 | 28 | 33 | ||
Heated term | 12.6kw | Steam pressure:0.294-0.588MPa Voltage:380V Three phase four wire | ||||||
Motor power | 0.75 | 1.1 | 1.5 | 2.2 | 4 | 3 | ||
Breeze motor power | 0.75 | 1.1 | 1.1 | 1.5 | 1.5×2 | 2.2 | ||
Overall dimensions | 800*1020*1530 | 1000×1400×1800 | 1190×1670×2100 | 1480×1840×2380 | 1760×200×2730 | 2650×1630×2720 | ||
Overall weight | 250 | 600 | 800 | 980 | 1300 | 1500 |
Model | HGQ15 | HGQ30 | HGQ50 | HGQ100 | HGQ120 | HGQ150 | HGQ200 |
Rated Capacity | 15kg | 30kg | 50kg | 100kg | 120kg | 150kg | 200kg |
Drum Dimension (mm) | Φ760*560 | Φ900*750 | Φ1050*930 | Φ1320*1055 | Φ1470*1055 | Φ1600*1150 | Φ1300*2150 |
Drum Speed (rpm ) | 33r/min | 33r/min | 33r/min | 33r/min | 33r/min | 28r/min | 33r/min |
Electric Heating Power | 12.6kw | 16.2kw | 27kw | ---- | ----- | ------ | ----- |
Motor Power | 0.75kw | 1.1kw | 1.5kw | 2.2kw | 3kw | 4kw | 3kw |
Fan power | 0.75kw | 1.1kw | 1.1kw | 1.5kw | 1.5kw*2 | 1.5kw*2 | 2.2kw |
Overall Dimension (mm) | 800*1020*1530 | 1000*1400*1800 | 1190*1670*2100 | 1480*1840*2380 | 1660*1840*2470 | 1760*2000*2730 | 2650*1630*2720 |
Overall Weight | 250kg | 600kg | 800kg | 980kg | 1100kg | 1300kg | 1300kg |
Model | HGQ15 | HGQ30 | HGQ50 | HGQ100 | HGQ120 | HGQ150 | HGQ200 |
Rated Capacity | 15kg | 30kg | 50kg | 100kg | 120kg | 150kg | 200kg |
Drum Dimension (mm) | Φ760*560 | Φ900*750 | Φ1050*930 | Φ1320*1055 | Φ1470*1055 | Φ1600*1150 | Φ1300*2150 |
Drum Speed (rpm ) | 33r/min | 33r/min | 33r/min | 33r/min | 33r/min | 28r/min | 33r/min |
Electric Heating Power | 12.6kw | 16.2kw | 27kw | ---- | ----- | ------ | ----- |
Motor Power | 0.75kw | 1.1kw | 1.5kw | 2.2kw | 3kw | 4kw | 3kw |
Fan power | 0.75kw | 1.1kw | 1.1kw | 1.5kw | 1.5kw*2 | 1.5kw*2 | 2.2kw |
Overall Dimension (mm) | 800*1020*1530 | 1000*1400*1800 | 1190*1670*2100 | 1480*1840*2380 | 1660*1840*2470 | 1760*2000*2730 | 2650*1630*2720 |
Overall Weight | 250kg | 600kg | 800kg | 980kg | 1100kg | 1300kg | 1300kg |
Industrial drying machine is a kind of equipment that is dried by hot air, which can dry wool, cotton clothes, bed sheets and quilt covers
1. It adopts computer automatic control, and can configure different drying temperature and drying time according to drying requirements to realize automatic drying.
2 The inner drum is made of bright stainless steel with excellent heat resistance, the inner wall is smooth, and the wear of clothes is reduced
3 Equipped with a high-efficiency radiator and a reasonable air duct, so that the hot air directly contacts the clothes, which greatly improves the drying efficiency and saves energy.
4 There are various models such as external steam radiator or electric heating radiator, or natural gas radiator to choose from
