Leather Soft Machine (HGQ100)

Quantity:
  • HGQ100
  • ISO9001
  • haifeng
  • 50sets /Month
  • China
  • Wooden Case
  • China
Leather crinkle machine, leather soft machine, leather machine
Leather dryer
100kg 120kg or 150kg and 200kg
This machine is for leather facotry to soft leather and crinkle the leather
The drum is made from high-quality stainless steel, we can also make the machines covered by all stainless steel.
Can be heated by hot oil or steam.
Big-size door is adopted for convenient fabric feeding and taking as well as transparent toughened glass is equipped for convenient view of fabric drying condition.
Terms of payment: T/T /LC
Our products are ISO9001 and CE certified.
The specification of 100kg tumbler dryer is as follows.
Model HGQ100
Capacity 100kg
Drum dimension diameter 1320mm*1055
Rotation 33rpm
Steam pressure 0.944 to 0.588Mpa
Motor power 2.2kw
Fan power 1.5kw
Overall dimension 1480mm*1840mm*2380mm
Weight 980kg
If you are interested in our machines, please not hesitate to contact us
 model  HGQ15  HGQ30  HGQ50  HGQ100 HGQ120  HGQ150   HGQ200
 rated capacity  15kg  30kg  50kg  100kg  120kg  150kg  200kg
 drum dimension
(mm)
 Φ760*560  Φ900*750  Φ1050*930  Φ1320*1055  Φ1470*1055  Φ1600*1150  Φ1300*2150
 drum speed (rpm )  33r/min  33r/min  33r/min  33r/min  33r/min  28r/min  33r/min
 electric heating power  12.6kw  16.2kw  27kw  ----  -----  ------  -----
 motor power  0.75kw  1.1kw  1.5kw  2.2kw  3kw  4kw  3kw
 fan power  0.75kw  1.1kw  1.1kw  1.5kw  1.5kw*2  1.5kw*2  2.2kw
 overall dimension
(mm)
800*1020*1530 1000*1400*1800 1190*1670*2100 1480*1840*2380 1660*1840*2470 1760*2000*2730 2650*1630*2720
 overall weight  250kg  600kg  800kg  980kg  1100kg  1300kg  1300kg
